| Drive Configuration | |
| Device Location: | Internal |
| Form Factor: | M.2 22x80mm |
| Storage Capacity: | 250 GB |
| Supports Data Channel: | PCIe NVMe 4.0 x4 |
| Certifications: | RoHs |
| Memory Technology: | 3D NAND |
| Flash Memory Cell Technology: | Triple-Level Cell |
| Included Accessories: | Quick Start Guide |
| Performance | |
| Maximum Random Read Rate: | 210000 IOPS |
| Maximum Random Write Rate: | 280000 IOPS |
| Maximum Sequential Read Rate: | 3200 MB/s |
| Maximum Sequential Write Rate: | 1300 MB/s |
| Total Bytes Written (TBW): | 160 TB |
| Reliability | |
| Mean Time Between Failures: | 1800000 hr |
| Solid State Drive Features: |
S.M.A.R.T. TRIM Support NVMe Support Halogen Free |
| Shock Tolerance Operating: | 1500G @ 0.5ms |
| Power Consumption | |
| Maximum Power Consumption: | 3 W |
| Environment | |
| Maximum Operating Ambient Temperature: | 70 °C |
| Minimum Operating Ambient Temperature: | 0 °C |
| Maximum Non-Operating Ambient Temperature: | 85 °C |
| Minimum Non-Operating Ambient Temperature: | -40 °C |
| Dimensions & Weight | |
| Width (mm): | 22.15 mm |
| Height (mm): | 2.23 mm |
| Depth (mm): | 80.15 mm |
 |
|
|
