SUPERMICRO MB 1xLGA2066, iC422, 8x DDR4 ECC, 8xSATA3, M.2, 6x PCI-E 3.0, 2x LAN,IPMI

SUPERMICRO MB 1xLGA2066, iC422, 8x DDR4 ECC, 8xSATA3, M.2, 6x PCI-E 3.0, 2x LAN, IPMI

Záruka: 24 měsíců | PN: MBD-X11SRL-F-O | Kód: 2859539 | CZ distribuce
Key Features   Intel® Xeon® W-2100 Processors, Intel® Xeon® W-2200 Processors, Single Socket LGA-2066 (Socket R4) supported, CPU TDP support Up to 165W TDP Intel® C422 Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots 3 PCI-E 3.0 x8, 1 PCI-E 3.0 x16, 1…
Momentálně nedostupné

Popis

Key Features
  1.
  2. Intel® Xeon® W-2100 Processors, Intel® Xeon® W-2200 Processors, Single Socket LGA-2066 (Socket R4) supported, CPU TDP support Up to 165W TDP
  3. Intel® C422
  4. Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots
  5. 3 PCI-E 3.0 x8,
    1 PCI-E 3.0 x16,
    1 PCI-E 3.0 x8 (in x16 slot),
    1 PCI-E 3.0 x4 (in x8 slot)
    M.2 Interface: 1 PCI-E 3.0 x4
    M.2 Form Factor: 2280/22110
    M.2 Key: M-Key
    Double Height Connector
  6. Dual LAN with Intel® i210 Gigabit Ethernet Controller
  7. Intel® C422 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

Links & Resources

Specifications
Product SKUs
MBD-X11SRL-F
  • X11SRL-F

Physical Stats
Form Factor
  • ATX
Dimensions
  • 12" x 9.6" (30.48cm x 24.38cm)

Processor/Cache
CPU
  • Intel® Xeon® W-2100 Processors, Intel® Xeon® W-2200 Processors
  • Single Socket LGA-2066 (Socket R4) supported, CPU TDP support Up to 165W TDP
Cores / Cache
  • 18 cores, 36 threads
Note
  • W-2200 CPU is supported on the motherboards with BIOS 2.0 or newer upon receiving from Supermicro
Note
  • To support 165W W-2200 CPUs, BIOS 2.0 & VRM update by Supermicro are required

System Memory
Memory Capacity
  • Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots
Memory Type
  • 2666/2400/2133MHz ECC DDR4 RDIMM, LRDIMM
DIMM Sizes
  • 4GB, 8GB, 16GB, 32GB, 64GB, 128GB
Memory Voltage
  • 1.2V
Error Detection
  • Corrects single-bit errors

On-Board Devices
Chipset
  • Intel® C422
SATA
  • Intel® C422 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
IPMI
  • ASPEED AST2500
Network Controllers
  • Dual LAN with Intel® i210 Gigabit Ethernet Controller
Graphics
  • Aspeed AST2500 BMC

Input / Output
SATA
  • 8 SATA3 (6Gbps) ports
LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
USB
  • 6 USB 2.0 ports (2 rear + 4 via headers)
  • 5 USB 3.2 Gen1 ports (2 rear + 2 via headers + 1 Type A)
Video Output
  • 1 VGA port
Serial Port / Header
  • 2 COM Ports (1 rear, 1 header)
TPM
  • TPM Header
Expansion Slots
PCI-E
  • 3 PCI-E 3.0 x8,
  • 1 PCI-E 3.0 x16,
  • 1 PCI-E 3.0 x8 (in x16 slot),
  • 1 PCI-E 3.0 x4 (in x8 slot)
M.2
  • M.2 Interface: 1 PCI-E 3.0 x4
  • Form Factor: 2280/22110
  • Key: M-Key
  • Double Height Connector

System BIOS
BIOS Type
  • AMI UEFI
BIOS Features
  • ACPI 6.2
  • SMBIOS 3.0 or later
  • UEFI 2.7

Management
Software
  • IPMI2.0, KVM with dedicated LAN, SUM, SuperDoctor® 5, Watchdog
Power Configurations
  • ACPI Power Management
  • CPU thermal trip support for processor protection
  • Power-on mode for AC power recovery

PC Health Monitoring
Voltage
  • +1.8V, +12V, +3.3V, +5V, +5V standby, 3.3V standby, 7-fan status, Chassis intrusion header, HT, Monitors CPU voltages, System temperature, VBAT
FAN
  • 7x 4-pin fan headers (up to 7 fans), Fan speed control, Overheat LED indication, PWM fan speed control, System level control
Temperature
  • PECI, CPU thermal trip support, Thermal Control for 6 Fan Connectors
LED
  • CPU / System Overheat LED, UID/Remote UID, Suspend static indicator LED
Other Features
  • ACPI power management, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, RoHS, UID

Operating Environment
Operating Temperature Range
  • 0°C ~ 50°C (32°F ~ 122°F)
Non-Operating Temperature Range
  • -20°C ~ 60°C (-4°F ~ 140°F)
Operating Relative Humidity Range
  • 10% ~ 85% (non-condensing)
Non-Operating Relative Humidity Range
  • 10% ~ 95% (non-condensing)

Parts List
Parts List (Bulk Package)
Name Part Number Qty Description
Motherboard MBD-X11SRL-F 1 X11SRL-F Motherboard
I/O Cables CBL-0044L 2 57.5CM SATA FLAT S-S PBF
I/O Shield MCP-260-00042-0N 1 STD I/O Shield for X11SRL-F with EMI Gasket

Parts List (Retail Package)
Name Part Number Qty Description
Motherboard MBD-X11SRL-F 1 X11SRL-F Motherboard
QRG MNL-2176-QRG 1 Motherboard Quick Reference Guide
I/O Cables CBL-0044L 6 57.5 cm SATA FLAT S-S PBF
I/O Shield MCP-260-00042-0N 1 STD I/O Shield for X11SRL-F with EMI Gasket


Chassis (Optimized for

X11SRL-F

)
Embedded Compact 1U 2U 3U Mid/Mini-Tower             4U/Tower
SC825TQC-R740LPB
SC825TQC-600LPB
SCLA25TQC-R609LP
SCLA26E1C4-R609LP
 SC733TQ-668B
 SC842TQC-668B
SC743AC-668B
= Most optimized Chassis for SuperServer Configuration
Blue color = Compatible
Green color = Global SKU & Compatible
Red dot & green color = Optimized + Global SKU
