Intel NUC 10 Performance kit - NUC10i5FNK2
TECHNICAL SPECIFICATIONS
|
Essentials |
|
|
Product Collection |
Intel NUC Kit with 10th Generation Intel Core™ Processors |
|
Code Name |
Products formerly Frost Canyon |
|
Status |
Launched |
|
Launch Date |
Q4'19 |
|
Supported Operating Systems |
Windows 10, 64-bit* |
|
Board Number |
NUC10i5FNB |
|
Board Form Factor |
UCFF (4" x 4") |
|
Socket |
Soldered-down BGA |
|
Internal Drive Form Factor |
M.2 SSD |
|
# of Internal Drives Supported |
1 |
|
Lithography |
14 nm |
|
TDP |
25 W |
|
DC Input Voltage Supported |
19 VDC |
|
Processor Included |
Intel Core™ i5-10210U Processor (6M Cache, up to 4.20 GHz) |
|
Intel vPro™ Platform Eligibility ‡ |
No |
|
# of Cores |
4 |
|
# of Threads |
8 |
|
Processor Base Frequency |
1.60 GHz |
|
Max Turbo Frequency |
4.20 GHz |
|
Warranty Period |
3 yrs |
|
Supplemental Information |
|
|
Embedded Options Available |
No |
|
Datasheet |
View now |
|
Description |
Other features: Includes far-field quad array microphones |
|
Memory & Storage |
|
|
Max Memory Size (dependent on memory type) |
64 GB |
|
Memory Types |
DDR4-2666 1.2V SO-DIMM |
|
Max # of Memory Channels |
2 |
|
Max Memory Bandwidth |
42.6 GB/s |
|
Max # of DIMMs |
2 |
|
ECC Memory Supported ‡ |
No |
|
Processor Graphics |
|
|
Processor Graphics ‡ |
Intel UHD Graphics |
|
Integrated Graphics ‡ |
Yes |
|
Graphics Output |
HDMI 2.0a; USB-C (DP1.2) |
|
# of Displays Supported ‡ |
3 |
|
Expansion Options |
|
|
PCI Express Revision |
Gen3 |
|
PCI Express Configurations ‡ |
M.2 slot with PCIe X4 lanes |
|
Removable Memory Card Slot |
SDXC with UHS-II support |
|
M.2 Card Slot (storage) |
22x42/80 |
|
I/O Specifications |
|
|
# of USB Ports |
7 |
|
USB Configuration |
2x front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C); 2x USB 2.0 via internal headers |
|
USB Revision |
2.0, 3.1 Gen2 |
|
USB 2.0 Configuration (External + Internal) |
0 + 2 |
|
USB 3.0 Configuration (External + Internal) |
2B 2F + 0 |
|
Total # of SATA Ports |
2 |
|
Max # of SATA 6.0 Gb/s Ports |
2 |
|
Audio (back channel + front channel) |
7.1 digital (HDMI mDP); L+R mic (F) |
|
Integrated LAN |
Intel Ethernet Connection I219-V |
|
Integrated Wireless‡ |
Intel Wi-Fi 6 AX201 |
|
Integrated Bluetooth |
Yes |
|
Consumer Infrared Rx Sensor |
Yes |
|
Additional Headers |
CEC, 2x USB2.0, FRONT_PANEL |
|
# of Thunderbolt™ 3 Ports |
1 |
|
Package Specifications |
|
|
Chassis Dimensions |
117 x 112 x 38mm |
|
Advanced Technologies |
|
|
Intel Optane™ Memory Supported ‡ |
Yes |
|
Intel Virtualization Technology for Directed I/O (VT-d) ‡ |
Yes |
|
Intel vPro™ Platform Eligibility ‡ |
No |
|
TPM |
No |
|
Intel HD Audio Technology |
Yes |
|
Intel Rapid Storage Technology |
Yes |
|
Intel Virtualization Technology (VT-x) ‡ |
Yes |
|
Intel Platform Trust Technology (Intel PTT) |
Yes |
|
Security & Reliability |
|
|
Intel AES New Instructions |
Yes |
